When you learn that your home has elevated radon, the next question is usually "what kind of system do I need?" The answer depends primarily on your foundation type. Here is a straightforward comparison of the main mitigation approaches, their strengths, and when each one is the best fit.
1. Sub-Slab Depressurization (SSD)
Sub-slab depressurization is the most common and effective radon mitigation method. It works by creating a vacuum beneath the concrete slab, drawing radon-laden soil gas away from the foundation and venting it safely above the roofline.
How It Works
- Core hole: A 4 to 5 inch hole is drilled through the basement or slab floor
- Suction pit: Approximately 12 inches of aggregate is removed beneath the slab to create a suction area
- PVC piping: 3 or 4 inch PVC pipe runs from the suction point up through or along the side of the home
- Radon fan: An inline radon fan mounted in the attic, garage, or on the exterior creates continuous negative pressure
- Exhaust point: The pipe terminates above the roofline, releasing radon safely into the outdoor air where it disperses
Strengths
- 95 to 99% radon reduction
- Works for most slab-on-grade and basement homes
- Quiet operation when properly installed
- Low operating cost ($50 to $150/year) with minimal maintenance
Considerations
- Requires access beneath the slab
- Pipe routing needs careful planning
- May need multiple suction points for large homes
- Not suitable for dirt-floor crawl spaces
2. Sub-Membrane Depressurization
For homes with crawl spaces that have dirt or gravel floors, sub-membrane depressurization is the standard approach. A heavy-duty polyethylene membrane is sealed over the dirt floor, and suction is applied beneath it.
- Membrane installation: A 6-mil or thicker polyethylene sheet is laid over the entire crawl space floor and sealed to the foundation walls with caulk or mechanical fasteners.
- Suction point: A PVC pipe penetrates the membrane and connects to a fan, creating negative pressure beneath the membrane.
- Effectiveness: When properly sealed, this method achieves radon reductions comparable to sub-slab systems (90 to 99%).
- Added benefits: The membrane also reduces moisture, helps control pests, and improves overall crawl space conditions.
3. Block Wall Suction
Homes with hollow concrete block (CMU) foundations can benefit from block wall suction. Radon can travel through the hollow cores of concrete blocks and enter the home through gaps at the top of the wall or through mortar joints.
This method applies suction to the hollow cores of the block wall, pulling radon from within the wall cavity before it enters the living space. It is often used in combination with sub-slab depressurization for maximum effectiveness.
4. Drain Tile / Sump Pit Suction
If your home has an existing sump pit or interior drain tile system, this infrastructure can sometimes be used as a radon suction point. The drain tile network beneath the floor provides a ready-made pathway to draw radon from a wide area.
Sump Pit Approach
The sump pit is sealed with a gastight cover and a suction pipe is attached. The pit connects to the drain tile network, providing broad sub-slab communication. Cost-effective when existing infrastructure is available.
When It Works Best
Ideal for homes with existing perimeter drain systems. The connected drain tile provides excellent suction coverage across the entire foundation. May not work if the drain tile is clogged or disconnected.
5. HRV/ERV Dilution Systems
Heat Recovery Ventilators and Energy Recovery Ventilators bring in fresh outdoor air while recovering energy from the outgoing air. They can reduce radon by dilution, typically lowering levels by 25 to 50%.
Important Limitation
HRVs and ERVs are not considered primary radon mitigation systems. They work through dilution rather than source removal. For homes with levels above 4 pCi/L, an active soil depressurization system is recommended as the primary mitigation method.
6. Choosing the Right System
The right system depends primarily on your foundation type.
System Selection Guide
- Poured concrete slab or basement: Sub-slab depressurization (SSD)
- Dirt-floor crawl space: Sub-membrane depressurization
- Hollow block foundation: Block wall suction (often combined with SSD)
- Home with sump pit: Sump pit suction (may serve as the SSD point)
- Multiple foundation types: Combination system tailored to each area
- Marginally elevated levels (2 to 4 pCi/L): Consider HRV/ERV as supplementary measure
7. Installation Considerations
Regardless of system type, several factors affect installation quality and effectiveness.
- Fan location: The fan should be placed outside the conditioned space (attic, exterior, or garage) so that any pipe leaks on the pressure side do not release radon into the home.
- Pipe routing: Interior, exterior, or garage routing each has aesthetic and practical trade-offs. Discuss options with your installer. For details, see our guide on radon pipe routing options.
- Manometer: A U-tube manometer should be installed on the pipe to provide visual confirmation that the system is operating correctly.
- Post-mitigation testing: Always test after installation to verify the system is achieving levels below 4 pCi/L (ideally below 2 pCi/L). See our mitigation cost guide for pricing by system type.
